Specifications
Description
Store availability
Delivery
Price development
| Technical details | |
| Warranty period | 3 year(s) |
| Processor | |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Processor socket | AM5 |
| Supported processor sockets | Socket AM5 |
| Memory | |
| Maximum internal memory | 256 GB |
| Supported memory clock speeds | 8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5200,4800,4400 MHz |
| Supported memory types | DDR5 |
| Memory channels | Dual-channel |
| Unbuffered memory |  |
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Supported memory clock speed (max) | 8200 MHz |
| Weight & dimensions | |
| Height | 35 mm |
| Width | 244 mm |
| Depth | 244 mm |
| Networking | |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Bluetooth version | 5.3 |
| Ethernet LAN | |
| Bluetooth | |
| LAN controller | Realtek RTL8125 |
| Wi-Fi | |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Realtek RTL8852CE |
| Internal I/O | |
| USB 2.0 connectors | 2 |
| CPU fan connector | |
| ATX Power connector (24-pin) | |
| Number of chassis fan connectors | 4 |
| Front panel audio connector | |
| TPM connector | |
| EPS power connector (8-pin) | |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 0 |
| Front panel connector | |
| 12V power connector | |
| RGB LED pin header | |
| Back panel I/O ports | |
| PS/2 ports quantity | 1 |
| Line-in | |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | |
| VGA (D-Sub) ports quantity | 0 |
| DVI-D ports quantity | 0 |
| WiFi-AP antenna jack | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Storage controllers | |
| RAID levels | 0, 1, 10 |
| Number of HDDs supported | 4 |
| RAID support | |
| Number of storage drives supported | 6 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, PCI Express 4.0, SATA III |
| Packaging data | |
| Package weight | 1.59 kg |
| Package depth | 268 mm |
| Package height | 68 mm |
| Package width | 270 mm |
| Packaging content | |
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software |
| Batteries included | |
| Screws included | |
| Antenna included | |
| Expansion slots | |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Number of M.2 (M) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| BIOS | |
| BIOS memory size | 256 Mbit |
| BIOS type | UEFI AMI |
| ACPI version | 5.0 |
| Clear CMOS jumper | |
| Desktop Management Interface (DMI) version | 2.7 |
| System Management BIOS (SMBIOS) version | 2.7 |
| Battery | |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery type | CR2032 |
| Number of battery cells | 1 |
| Battery weight | 3 g |
| Lithium weight per battery | 0.07 g |
| Other features | |
| Weight | 1.5 kg |
| Graphics | |
| Maximum resolution | 4096 x 2160 pixels |
| Parallel processing technology support | Not supported |
| DirectX version | 12.0 |
| HDCP | |
| Features | |
| Motherboard chipset | AMD B840 |
| Motherboard form factor | Micro ATX |
| Product colour | Dark brown |
| Audio output channels | 7.1 channels |
| Cooling type | Passive |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Power source type | ATX |
| Motherboard chipset family | AMD |
| Component for | PC |
| Audio chip | Realtek ALC897 |
| Logistics data | |
| Products per shipping (inner) case | 1 pc(s) |
| EAN | 4719331867331 |
| Source: Icecat.biz | |
The Gigabyte B840M Elite WIFI6E is a micro-ATX motherboard designed for gamers and PC enthusiasts looking to build a high-performance, compact system based on the AMD AM5 platform. Supporting AMD Ryzen™ 7000, 8000, and 9000 Series processors, this motherboard offers a balance of essential features and reliable performance. With its robust VRM design and advanced thermal solutions, the B840M Elite WIFI6E ensures stable power delivery and efficient cooling, even when overclocking. The inclusion of WIFI 6E and 2.5GbE LAN provides cutting-edge connectivity for seamless online gaming and content streaming.
This motherboard features PCIe 4.0 slots for high-speed graphics cards and NVMe SSDs, allowing for fast data transfer rates and smooth gameplay. The B840M Elite WIFI6E also boasts ample USB connectivity, including USB 3.2 Gen2x2 ports, for connecting a wide range of peripherals. The user-friendly BIOS interface and DIY-friendly features like EZ-Latch designs simplify the building process, making it an excellent choice for both novice and experienced builders. Furthermore, the motherboard supports DDR5 memory with speeds up to 8200MT/s, enhancing overall system responsiveness and gaming performance.
Key Features- AMD Socket AM5: Supports AMD Ryzen™ 7000/8000/9000 Series Processors
- Chipset: AMD B840
- Memory: 4 x DIMM, Dual Channel DDR5, up to 256GB, 8200MT/s (OC)
- Expansion Slots: 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x4
- M.2 Slots: 2 x M.2 slots with NVMe PCIe 4.0 support
- SATA Ports: SATA 6Gb/s ports
- Networking: 2.5GbE LAN
- Wireless: Wi-Fi 6E with directional Ultra-high gain antenna
- USB Ports: USB 3.2 Gen2x2, USB 3.2 Gen 1, USB 2.0
- Audio: Realtek Audio Codec
- Form Factor: Micro-ATX
- BIOS: UC BIOS with user-friendly interface, Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan
- Gigabyte B840M Elite WIFI6E Motherboard
- I/O Shield
- SATA Cables
- Wi-Fi Antenna
- User Manual
- Driver CD/USB
- M.2 Screws/Standoffs
