| Ports & interfaces | |
| ATX Power connector (24-pin) |  |
| Floppy disk drive connector | |
| PCI Express connector | |
| Motherboard power connector | 24-pin ATX |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| EPS power connector (8-pin) | |
| PCI Express power connectors (8-pin) | 1 |
| CPU power connector (4+4 pin) | |
| PCI Express power connectors (6+2 pin) | 1 |
| Cabling type | Modular |
| Weight & dimensions | |
| Weight | 2.27 kg |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 150 mm |
| Energy management | |
| Input current | 6 - 12 A |
| Nominal power | 550 W |
| Efficiency | 92% |
| Power protection features | Over current,Over voltage,Overload |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 540 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 45 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Total power | 550 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Certificates | |
| RoHS compliance | |
| 80 PLUS certification | 80 PLUS Gold |
| Packaging content | |
| Manual | |
| Warranty card | |
| Cooling | |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Fan location | Top |
| Design | |
| Product colour | Black |
| Performance | |
| Purpose | PC |
| On/off switch | |
| Power supply unit (PSU) form factor | ATX |
| EAN | 4250812407214 |
| Warranty | 1 year |
- 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads
- Highest quality Japanese brand capacitors ensure long-term reliability
- Fully Modular to reduce clutter and improve airflow
- NVIDIA SLI & AMD Crossfire Ready
- Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)
- 5 Year Warranty and unparalleled EVGA Customer Support
