Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Ports & interfaces | |
Motherboard power connector | 20+4 pin ATX |
Floppy drive power connector | 1 |
Number of SATA power connectors | 4 |
Peripheral (Molex) power connectors (4-pin) | 4 |
EPS power connector (8-pin) | |
CPU power connector (4+4 pin) | |
PCI Express power connectors (6+2 pin) | 1 |
Weight & dimensions | |
Weight | 1.28 kg |
Height | 86 mm |
Width | 150 mm |
Depth | 140 mm |
Energy management | |
Input current | 3 A |
Nominal power | 650 W |
Power protection features | Over current, Over voltage, Short circuit |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 150 W |
Combined power (+12V) | 550 W |
Combined power (+5V) | 150 W |
Max output current (+3.3V) | 28 A |
Max output current (+12V) | 18 A |
Max output current (+5V) | 28 A |
Max output current (-12V) | 0.8 A |
Max output current (+5Vsb) | 2.5 A |
AC input frequency | 50 - 60 Hz |
AC input voltage | 115 - 230 V |
Max output current (+12V4) | 18 A |
Max output current (+12V3) | 18 A |
Max output current (+12V2) | 18 A |
Max output current (+12V1) | 18 A |
Total power | 650 W |
Maximum input current (@110V) | +12V1,+12V2,+12V3,+12V4,+3.3V,+5V,+5Vsb,-12V |
Packaging data | |
Package weight | 1.62 kg |
Other features | |
Package dimensions (WxDxH) | 200 x 200 x 95 mm |
Design | |
Product colour | Black |
Number of fans | 1 fan(s) |
On/off switch | |
Cooling type | Active |
Fan diameter | 12 cm |
Fan location | Top |
Performance | |
Certification | CE, TUV, FCC |
Noise level | 21 dB |
Purpose | PC |
ATX version | 2.2 |
Power supply unit (PSU) form factor | ATX |
EAN | 4260133121096 |
Warranty | 1 year |
