| Technical details | |
| Memory bandwidth (max) | 6 GB/s |
| Processor | |
| Compatible processor series | Core i3,Core i5,Core i7 |
| Processor family | Intel |
| Processor socket | LGA 1150 |
| Intel Core i3/i5/i7/i9 series | i3-4xxx,i5-4xxx,i7-4xxx |
| Memory | |
| Maximum internal memory | 32 GB |
| Non-ECC |  |
| Memory voltage | 1.35,1.5 V |
| Supported memory clock speeds | 1600,2133,2200,2400,2600,2800,3000 MHz |
| Supported memory types | DDR3 |
| Unbuffered memory | |
| Memory slots type | DIMM |
| Supported memory module capacities | 1GB,2GB,4GB,8GB |
| Number of memory slots | 4 |
| Weight & dimensions | |
| Width | 304.8 mm |
| Depth | 244 mm |
| Networking | |
| Ethernet LAN | |
| LAN controller | Intel I210AT,Intel I217V |
| Ethernet interface type | Gigabit Ethernet |
| Internal I/O | |
| Number of SATA connectors | 8 |
| USB 2.0 connectors | 6 |
| Number of COM connectors | 2 |
| Number of IEEE1394 connectors | 2 |
| Power fan connector | |
| TPM connector | |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 4 |
| Number of SATA III connectors | 8 |
| Supported storage drive interfaces | Serial ATA III |
| Back panel I/O ports | |
| PS/2 ports quantity | 2 |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Microphone in | |
| VGA (D-Sub) ports quantity | 1 |
| DVI-D ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Packaging content | |
| Bundled software | SuperDoctor® III Watch Dog |
| Expansion slots | |
| PCI slots | 2 |
| PCI Express x1 (Gen 2.x) slots | 3 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| BIOS | |
| BIOS memory size | 128 MB |
| BIOS type | AMI |
| ACPI version | 5.0 |
| Performance | |
| Certification | RoHS |
| Motherboard chipset | Intel Z87 |
| Audio system | Realtek HD Audio |
| Motherboard form factor | ATX |
| RAID levels | 0, 1, 5, 10 |
| Audio output channels | 7.1 channels |
| Motherboard chipset family | Intel |
| Component for | PC |
| Features | |
| Motherboard form factor | ATX |
| EAN | 672042136834 |
| Warranty | 1 year |
Key Features
1. Single socket H3 (LGA 1150) supports Intel® 4th gen. Core i7/i5/i3 processors
2. Intel® Z87 Chipset
3. Up to 32GB DDR3 non-ECC 1600MHz UDIMM in 4 sockets; Overclocking* support up to 3000MHz
4. Dual Gigabit Ethernet LAN ports (1x Intel® i217V & 1x Intel® i210AT)
5. 8x SATA3 (6Gbps)
6. 2 (x16) PCI-E 3.0, 3 (x1) PCI-E 2.0, and 2 5V PCI 32-bit slots
7. 6x USB 3.0 (2 rear + 4 via headers) 10x USB 2.0 (4 rear + 6 via headers)
8. HD Audio 7.1 channel connector by Realtek ALC1150
9. 1x DOM power connector and
1x SPDIF Out Header
10. UEFI BIOS support
1. Single socket H3 (LGA 1150) supports Intel® 4th gen. Core i7/i5/i3 processors
2. Intel® Z87 Chipset
3. Up to 32GB DDR3 non-ECC 1600MHz UDIMM in 4 sockets; Overclocking* support up to 3000MHz
4. Dual Gigabit Ethernet LAN ports (1x Intel® i217V & 1x Intel® i210AT)
5. 8x SATA3 (6Gbps)
6. 2 (x16) PCI-E 3.0, 3 (x1) PCI-E 2.0, and 2 5V PCI 32-bit slots
7. 6x USB 3.0 (2 rear + 4 via headers) 10x USB 2.0 (4 rear + 6 via headers)
8. HD Audio 7.1 channel connector by Realtek ALC1150
9. 1x DOM power connector and
1x SPDIF Out Header
10. UEFI BIOS support
