Dell Networking S3048-ON - Kytkin - L3 - Hallinnoitu - 48 x 10/100/1000 + 4 x 10 Gigabit SFP+ - räkkiin asennettava

Ports & interfaces
USB 2.0 ports quantity	1
Console port	RJ-45
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
SFP+ module slots quantity	4
Weight & dimensions
Weight	5.84 kg
Height	44 mm
Width	434 mm
Depth	320 mm
Energy management
Power consumption (typical)	65 W
Number of power supply units	1
Redundant power supply (RPS) support
Input current	1 A
AC input frequency	50 - 60 Hz
AC input voltage	90 - 264 V
Power consumption (max)	87 W
Power supply included
Operational conditions
Operating altitude	0 - 3048 m
Operating relative humidity (H-H)	5 - 85%
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	5 - 95%
Heat dissipation	290 BTU/h
Protocols
Management protocols	SMIv1, SMIv2, SNMPv1, SNMPv2, SNMPv3, OSPF, OSPFv2, OSPFv3, IGMPv1, IGMPv2, IGMPv3, RMON, RMONv2
Supported network protocols	IPv4, IPv6, ICMP, ARP, DNS, LLDP, MSTP, RSTP, UDP, TCP, Telnet, FTP, NTPv3, TACACS, CIDR, BOOTP, MLD, MLDv2, RIPv1, RIPv2, OSPFv2, OSPFv3, NSSA, MD5, MSDP, SSH
Networking
Full duplex
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Flow control support
Link aggregation
VLAN support
Routing entries	16000
10G support
Copper ethernet cabling technology	1000BASE-T, 1000BASE-TX, 100BASE-T
Data transmission
MAC address table	80000 entries
Switching capacity	260 Gbit/s
Number of queues	8
Forwarding rate	131 Mpps
Packet buffer memory	4 MB
Latency (1 Gbps)	3.7 µs
Latency (10 Gbps)	1.8 µs
Certificates
Certification	ASNZS CISPR 22, ICES-003, EN 55022, VCCI V3, EN300 386 V1.4.1, EN 55024, EN 61000-3-2, EN 61000-3-3, EN61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, RoHS
Management features
MIB support	Y
Switch layer	L2/L3
Web-based management
System event log
Switch type	Managed
Design
Rack mounting
Safety	UL/CSA 60950-L, EN 60950-1, IEC 60950-1, EN 60825-1, EN 60825-2, FDA 21 CFR 1040.10/1040.11
Form factor	1U
LED indicators
Product colour	Black
Stackable
Ventilation system	Front-to-back airflow
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Performance
Internal memory	2048 MB
Noise level	36 dB
Built-in processor
Physical stacking (units)	6
Logistics data
Harmonized System (HS) code	85176990
Multicast features
Multicast support
EAN	4053162981775
Warranty	1 year
Source: Icecat.biz
