HPE Aruba 2930F 24G PoE+ 4SFP+ Basic Layer3 Switch (JL255A) with 24x 10/100/1000T PoE+ (Max 370 W) + 4x SFP+ 1/10GbE ports.Switching capacity 128 Gbps, Throughp
Manufacturer: HEWLETT PACKARD ENTERPRISE
ID: JL255A#ABB
Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| Console port | RJ-45/micro-USB |
| Installed SFP+ modules quantity | 0 |
| Installed SFP modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP+ module slots quantity | 4 |
| Weight & dimensions | |
| Weight | 3.9 kg |
| Height | 304.2 mm |
| Width | 43.9 mm |
| Depth | 442.5 mm |
| Energy management | |
| Power source | AC |
| AC input frequency | 50/60 Hz |
| AC input voltage | 200 - 240 V |
| Power consumption (max) | 445 W |
| Power supply included |  |
| Operational conditions | |
| Operating relative humidity (H-H) | 15 - 95% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage relative humidity (H-H) | 15 - 95% |
| Heat dissipation | 258 BTU/h |
| Protocols | |
| Management protocols | SNMPv1, SNMPv2, SNMPv3 |
| Routing protocols | RIPng, VRRP |
| IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
| Networking | |
| Full duplex | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Link aggregation | |
| Rate limiting | |
| Auto MDI/MDI-X | |
| Spanning tree protocol | |
| VLAN support | |
| 10G support | |
| Auto-sensing | |
| Virtual LAN features | Private VLAN |
| Half duplex | |
| Data transmission | |
| MAC address table | 32768 entries |
| Switching capacity | 128 Gbit/s |
| Packet buffer memory | 12.38 MB |
| Latency (1 Gbps) | 3.8 µs |
| Latency (10 Gbps) | 1.6 µs |
| Throughput | 95.2 Mpps |
| Security | |
| Access Control List (ACL) | |
| SSH/SSL support | |
| Authentication type | RADIUS, TACACS+ |
| Authentication | MAC-based authentication, Web-based authentication |
| Management features | |
| Switch layer | L3 |
| Quality of Service (QoS) support | |
| Web-based management | |
| Switch type | Managed |
| Design | |
| Rack mounting | |
| Form factor | 1U |
| Stackable | |
| Airflow direction | Side-to-side airflow |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Total Power over Ethernet (PoE) budget | 370 W |
| Performance | |
| Processor frequency | 1016 MHz |
| Internal memory | 1024 MB |
| Processor model | ARM Cortex-A9 |
| Flash memory | 4096 MB |
| Memory type | DDR3-SDRAM |
| Built-in processor | |
| Virtual stacking (units) | 8 |
| Multicast features | |
| Multicast support | |
| EAN | 190017007014 |
| Warranty | 5 years |
| Source: Icecat.biz | |
The HPE Aruba Networking 2930F Switch Series is designed for digital workplaces optimized for mobile users. These powerful Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like HPE Aruba Networking ClearPass Policy Manager, HPE Aruba Networking Management Software (AirWave) and cloud-based HPE Aruba Networking Central. HPE Aruba Networking Virtual Switching Framework (VSF) provides stacking scale and simplicity for enterprise edge, SMB and branch offices. The 2930F delivers performance and value with support for RIP routing, Access OSPF, 10 GbE uplinks, up to 740W PoE+, robust QoS, and requires no software licensing.
What is new supporting point:
Convenient built-in 1 GbE or 10 GbE uplinks and up to 740W PoE+.
Scale with 8-member stacking.
Simplify with Zero Touch Provisioning (ZTP) and cloud-based HPE Aruba Networking Central support.
The HPE Aruba Networking 2930F Switch Series is a family of Layer 3 stackable switches that are easy to deploy and manage, providing scale for enterprise, SMB and branch access networks.
