Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Manuals
| Ports & interfaces | |
| Console port | RJ-45 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP module slots quantity | 2 |
| Weight & dimensions | |
| Weight | 4.7 kg |
| Height | 43.7 mm |
| Width | 485 mm |
| Depth | 285.4 mm |
| Energy management | |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 250 W |
| Power supply included |  |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -5 - 40 °C |
| Networking | |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto MDI/MDI-X | |
| Number of VLANs | 255 |
| Spanning tree protocol | |
| VLAN support | |
| 10G support |  |
| Data transmission | |
| MAC address table | 16384 entries |
| Switching capacity | 52 Gbit/s |
| Jumbo frames support | |
| Forwarding rate | 38.69 Mpps |
| Jumbo frames | 9216 |
| Certificates | |
| Certification | CE, FCC, IC |
| Management features | |
| Switch layer | L2 |
| Switch type | Managed |
| Packaging content | |
| Cables included | AC |
| Design | |
| Rack mounting | |
| Form factor | 1U |
| LED indicators | Activity, Link, PoE, Speed, Status |
| Wall mountable | |
| Product colour | Grey |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) power per port | 34.2 W |
| Performance | |
| Noise level | 53 dB |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| EAN | 0810354023149 |
| Warranty | 2 years |
| Source: Icecat.biz | |
Advanced Port Management
Each switch port offers custom settings: port name, PoE, network/VLAN configuration, and operation mode (switching, mirroring, or aggregate) – as well as 802.1X Authentication and Radius VLAN support.
MULTI-SITE MANAGEMENT
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
OPTICAL FIBRE BACKHAUL
Two SFP ports support uplinks of up to 1 Gbps.
VERSATILE MOUNTING OPTIONS
The UniFi Switch can be placed on a desktop or mounted on a wall or in a rack.
UNIFI CONTROLLER
You can access any managed UniFi Switch through the UniFi Controller to configure a variety of features:
- Operation mode (switching, mirroring, or aggregate) per port
- Network/VLAN configuration
- Jumbo frame and flow control services
- Network settings
- Storm control setting per port
- Spanning tree configuration
- 802.1x control and RADIUS VLAN
- Debug terminal option for command-line interface
Each switch port offers custom settings: port name, PoE, network/VLAN configuration, and operation mode (switching, mirroring, or aggregate) – as well as 802.1X Authentication and Radius VLAN support.
MULTI-SITE MANAGEMENT
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
OPTICAL FIBRE BACKHAUL
Two SFP ports support uplinks of up to 1 Gbps.
VERSATILE MOUNTING OPTIONS
The UniFi Switch can be placed on a desktop or mounted on a wall or in a rack.
UNIFI CONTROLLER
You can access any managed UniFi Switch through the UniFi Controller to configure a variety of features:
- Operation mode (switching, mirroring, or aggregate) per port
- Network/VLAN configuration
- Jumbo frame and flow control services
- Network settings
- Storm control setting per port
- Spanning tree configuration
- 802.1x control and RADIUS VLAN
- Debug terminal option for command-line interface
