Specifications
Description
Store availability
Delivery
Price development
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Basic switching RJ-45 Ethernet ports quantity | 1 |
Weight & dimensions | |
Weight | 299 g |
Height | 27.6 mm |
Width | 132 mm |
Depth | 93.3 mm |
Energy management | |
Power consumption (typical) | 632 W |
Number of power supply units | 1 |
Output current | 1.25 A |
Surge protection voltage | 4 kV |
Power consumption (max) | 63 W |
Power supply included | |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 90% |
Networking | |
Full duplex | |
Networking standards | IEEE 802.3,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x |
Flow control support | |
10G support | |
Data transmission | |
MAC address table | 1000 entries |
Switching capacity | 1 Gbit/s |
Management features | |
Switch type | Unmanaged |
Other features | |
Cabling technology | 10/100Base-T(X) |
Input voltage | 51 V |
Ethernet LAN (RJ-45) ports | 5 |
Ethernet LAN data rates | 10,100 Mbit/s |
Design | |
Rack mounting | |
Product colour | Blue |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) ports quantity | 4 |
Total Power over Ethernet (PoE) budget | 58 W |
Power over Ethernet (PoE) power per port | 15.4 W |
Performance | |
Maximum data transfer rate | 100 Mbit/s |
EAN | 6954273632663 |
Warranty | 3 years |
Source: Icecat.biz |
- Optional 820 ft (250 m) Extended Transmission Mode
- 4 x 10/100 Mbps Auto-MDIX Ports
- IEEE 802.3at/af PoE Compliant
- 30 Watts per PoE Port, PoE Power Budget 58 W
- 4 kV Surge Protection
- IEEE 802.3x Flow Control Support
- Plug-and-Play Installation
- 1 Gbps Switching Fabric
- 448 Kbits RAM Data Buffer
- K MAC Address Entries
- Sturdy Metal Enclosure
