Key Specifications
Choose one or multiple features to search for items that have the same specifications.Processor | |
Processor model | D1508 |
Processor manufacturer | Intel |
Processor lithography | 14 nm |
Processor family | Intel Pentium |
Processor socket | BGA 1667 |
Stepping | V2 |
Processor cores | 2 |
Processor code | SR2DQ |
Processor threads | 4 |
PCI Express slots version | 2.0,3.0 |
Processor operating modes | 64-bit |
Processor boost frequency | 2.6 GHz |
Processor cache | 3 MB |
Scalability | 1S |
CPU configuration (max) | 1 |
PCI Express configurations | 1x16,1x4,1x8 |
Processor frequency | 2.2 GHz |
Thermal Design Power (TDP) | 25 W |
Processor codename | Broadwell |
Processor cache type | L3 |
Maximum internal memory supported by processor | 128 GB |
ECC supported by processor | ![]() |
Processor package size | 37.5 x 37.5 mm |
Conflict-Free processor | ![]() |
Memory | |
Internal memory type | DDR4 |
Memory slots | 2 |
Maximum RAM supported | 32 GB |
Internal memory | 8 GB |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
USB port | ![]() |
Weight & dimensions | |
Weight | 5.2 kg |
Height | 166 mm |
Width | 282 mm |
Depth | 243 mm |
Energy management | |
Power consumption (typical) | 126.89 W |
Power consumption (sleep) | 56.92 W |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Power supply unit (PSU) capacity | 250 W |
Operational conditions | |
Operating altitude | 0 - 3048 m |
Operating relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -20 - 60 °C |
Operating temperature (T-T) | 5 - 40 °C |
Networking | |
Ethernet LAN | ![]() |
Wake-on-LAN ready | ![]() |
Wi-Fi | ![]() |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
iSCSI support | ![]() |
Storage | |
RAID levels | 0,1,5,6,10,JBOD |
Supported file systems | BTRFS,FAT,HFS+,NTFS,ext3,ext4 |
RAID support | ![]() |
Storage drive size | 2.5/3.5" |
Storage drive interface | Serial ATA |
Number of storage drives supported | 6 |
Storage drive sizes supported | 2.5,3.5" |
Storage drives installed | ![]() |
Maximum supported storage capacity | 60 TB |
Installed storage drive type | ![]() |
Supported storage drive types | HDD & SSD |
Hot-swap drive bays | ![]() |
Supported storage drive interfaces | Serial ATA, Serial ATA II, Serial ATA III |
Certificates | |
Certification | FCC Class B CE Class B BSMI Class B |
Operating system/software | |
Windows operating systems supported | Windows 10,Windows 7 |
Mac operating systems supported | Mac OS X 10.11 El Capitan |
Packaging content | |
Cables included | AC, LAN (RJ-45) |
External power adapter | ![]() |
Quick installation guide | ![]() |
Other features | |
Processor ARK ID | 91558 |
Design | |
Chassis type | Desktop |
Cable lock slot | ![]() |
LED indicators | Alarm, HDD, LAN, Status |
Product colour | Black |
Number of fans | 2 fan(s) |
Cooling type | Active |
Fan diameter | 9.2 cm |
Cable lock slot type | Kensington |
Drive bay locking | ![]() |
Fan diameter 2 | 9.2 cm |
Processor special features | |
Intel® Identity Protection Technology (Intel® IPT) | ![]() |
Intel® Hyper Threading Technology (Intel® HT Technology) | ![]() |
Intel® Turbo Boost Technology | 2.0 |
Intel® AES New Instructions (Intel® AES-NI) | ![]() |
Enhanced Intel SpeedStep Technology | ![]() |
Execute Disable Bit | ![]() |
Idle States | ![]() |
Thermal Monitoring Technologies | ![]() |
Intel Trusted Execution Technology | ![]() |
Intel Enhanced Halt State | ![]() |
Intel VT-x with Extended Page Tables (EPT) | ![]() |
Embedded options available | ![]() |
Intel TSX-NI | ![]() |
Intel® Secure Key | ![]() |
Intel 64 | ![]() |
Intel® OS Guard | ![]() |
UART | ![]() |
Intel Virtualization Technology for Directed I/O (VT-d) | ![]() |
Maximum number of PCI Express lanes | 32 |
Intel Identity Protection Technology version | 1.00 |
Intel Secure Key Technology version | 1.00 |
Intel Virtualization Technology (VT-x) | ![]() |
Intel TSX-NI version | 1.00 |
Memory types supported by processor | DDR3-SDRAM,DDR4-SDRAM |
Memory channels supported by processor | Dual |
Performance | |
Type | NAS |
Number of users | 16000 user(s) |
Noise level | 25.5 dB |
Access Control List (ACL) | ![]() |
Reset button | ![]() |
On/off switch | ![]() |
Built-in optical drive | ![]() |
Device class | Small & Medium Business |
Backup function | ![]() |
Backup features | Cloud, iSCSI LUN |
EAN | 4711174722778 |
Warranty | 3 years |
DiskStation DS3018xs
Powerful 6-bay NAS designed for work-intensive businesses
High-performance NAS server with scaling flexibility
Powered by a dual-core processor with AES-NI hardware encryption engine, Synology DiskStation DS3018xs is a brand new 6-bay NAS that comes with a PCIe slot and can be installed with a 10GbE network interface card or a dual M.2 SSD adapter card. SSD cache support enhances network speeds and boosts performance, allowing DS3018xs to meet data-intensive requirements.
Supercharge your storage with speedy performance
Equipped with dual-channel memory and a PCIe slot, DS3018xs supports installing the dual M.2 SSD adapter card, M2D17, or the 10GbE NIC, for high-IOPS system cache and ultra-fast data transmission respectively.
Next-generation file system for better data protection
The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overhead. While ensuring high-level data integrity, it also offers flexible, efficient data protection and recovery tools.
- Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
- Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
- File or folder level data restoration makes data recovery fast and flexible
- Automatic file self-healing detects and recovers corrupted files without user intervention
Fully certified storage virtualization solutions
Synology iSCSI storage fully supports most virtualization solutions to enhance work efficiency with easy management interface. VMware vSphere 6 and VAAI integration helps offload storage operations and optimizes computation efficiency. Windows Offloaded Data Transfer (ODX) speeds up data transfer and migration rate. OpenStack Cinder support turns your Synology NAS into a block-based storage component.
Digital asset protection
Powered by Synology DiskStation Manager (DSM), Synology NAS offers advanced security measures to protect against sudden data loss and potential security holes.
Security Advisor
Analyzes system settings, password strength, network preferences, and removes any possible malware.
AES 256-bit encryption
Encrypt shared folders and network data transmission to keep data from unauthorized access.
2-step verification
Prevent others from logging in to your DSM by generating a one-time password (OTP) on your mobile device.
Trust Level
Customize the trust level in Package Center to avoid installing packages from untrusted sources, safeguarding your NAS from unknown or tampered package files.
5 year warranty
Synology's 5-year limited warranty provides hardware replacement and technical support via email and telephone services, maximizing your enterprises' return on investment.
Powered by Synology DSM
CMS
Manage multiple Synology NAS servers simultaneously on a centralized interface to increase business efficiency.
MailPlus
Secure, reliable, and private mail server solution with an intuitive and modern mail client.
High Availability
Ensures seamless service transition between clustered servers in the event of a server failure.
Office
Collaborate together on spreadsheets and documents on your own private cloud.
Snapshot Replication
Provides schedulable and instantaneous data protection for shared folders and virtual machines on iSCSI LUNs in the event of disaster.
Surveillance Station
Complete surveillance solution for recording, monitoring, and management.
