HPE HPN FlexFabric 5945 Switch 4 Slots VXLAN VTEP OVSDB Support IPv6
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.Ports & interfaces | |
SFP module slots quantity | 4 |
Weight & dimensions | |
Weight | 18.1 kg |
Height | 88.1 mm |
Width | 440 mm |
Depth | 660 mm |
Energy management | |
Power consumption (typical) | 650 W |
AC input voltage | 100 - 240 V |
DC input voltage | 48 - 60 V |
Power consumption (max) | 650 W |
Operational conditions | |
Heat dissipation | 2348 BTU/h |
Data transmission | |
Switching capacity | 6400 Gbit/s |
Management features | |
Switch type | Managed |
Design | |
Rack mounting | ![]() |
Product colour | Black |
Stackable | ![]() |
Performance | |
Internal memory | 4096 MB |
Flash memory | 1024 MB |
Physical stacking (units) | 10 |
Logistics data | |
Harmonized System (HS) code | 85176990 |
EAN | 0190017209685 |
Warranty | 5 years |
Source: Icecat.biz |
The HPE Networking Comware Switch Series 5945 are high-density, ultra-low-latency, and top-of-rack (ToR) switches ideally suited for deployment at the aggregation or server access layer of large enterprise data centers. The HPE 5945 Series is also powerful enough for deployment at the core layer of medium-sized enterprises. With the increase in virtualized applications and server-to-server traffic, customers require spine and ToR switches that can meet their throughput requirements. With the HPE 5945 Series, data centers can now support up to 100GbE per port, allowing high performance server connectivity and the capabilities to handle virtual environments. The HPE Networking Comware Switch Series 5945 provides choices that fit your budget and IT environment by cut-through with ultra-low-latency and wire speed, offering different port density and speeds of 100GbE/40GbE/25GbE/10GbE spine/ToR connectivity.
What is new supporting point:
Greater flexibility with two/four slot options for varying use cases such as MACsec 256-bit encryption, high-performance DC leaf, storage networking and NVMe storage.
New made in USA TAA-compliant SKUs offer heightened security via manual and automated source code analysis to address common programming issues, easing concerns about "made in China" products.
High-density 100GbE/40GbE/25GbE/10GbE spine/top-of-rack (ToR) connectivity and Cut-through switching with low-latency and wire speed performance.
New 32G/16G support for storage networking and ROCE V1/V2 for RDMA High-Performance computing.VXLAN, EVPN, and MPLS support for virtualized environments.
IPv4 and IPv6 support with full L2/L3 features and PTP 1588V2 for Boundary Clock, Transparent Clock, End to End/Peer to Peer Transparent Clock.
HPE Aruba Networking IMC Orchestrator and Analyzer for enhanced network operations with orchestration, automation, and analytical capabilities.
