| Ports & interfaces | |
| Console port | RJ-45 |
| Installed SFP+ modules quantity | 0 |
| Installed SFP modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| SFP+ module slots quantity | 4 |
| Weight & dimensions | |
| Weight | 6 kg |
| Height | 43.6 mm |
| Width | 43.6 mm |
| Depth | 400 mm |
| Energy management | |
| Power source | AC |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| DC input voltage | 54 - 57 V |
| Power consumption (max) | 478 W |
| Power supply included |  |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -5 - 45 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Protocols | |
| Routing protocols | OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2 |
| IPv4 FIB entries | 512 |
| IPv6 FIB entries | 256 |
| Networking | |
| Full duplex | |
| Networking standards | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| IP routing | |
| Auto MDI/MDI-X | |
| Spanning tree protocol | |
| VLAN support | |
| 10G support | |
| Auto-sensing | |
| Data transmission | |
| MAC address table | 16384 entries |
| Switching capacity | 176 Gbit/s |
| Jumbo frames support | |
| Latency (1 Gbps) | 5 µs |
| Latency (10 Gbps) | 3 µs |
| Throughput | 131 Mpps |
| Security | |
| Access Control List (ACL) | |
| IGMP snooping | |
| Authentication type | HWTACACS, RADIUS |
| Authentication | MAC-based authentication |
| DHCP features | DHCP server |
| Management features | |
| Switch layer | L3 |
| Quality of Service (QoS) support | |
| Web-based management | |
| Switch type | Managed |
| Design | |
| Rack mounting | |
| Form factor | 1U |
| Stackable | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Total Power over Ethernet (PoE) budget | 370 W |
| Performance | |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Memory type | SDRAM |
| Physical stacking (units) | 9 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Multicast features | |
| Multicast support | |
| EAN | 190017499697 |
| Warranty | 5 years |
| Source: Icecat.biz | |
The HPE Networking Comware Switch Series 5140 EI delivers scalability, high availability, and low TCO at the access layer of medium and large enterprise campus networks. The series offers enterprise-class QoS and security, HPE Intelligent Resilient Fabric (IRF) stacking, static layer 3 routing and RIP; convenient fixed 10 GbE uplink ports, PoE+, ACLs, and IPv6; and delivers energy savings with Energy Efficient Ethernet. The HPE Networking Comware Switch Series 5140 EI also includes Smart Management Center (SmartMC), an embedded network management tool that can be leveraged at no additional cost by small and medium networks for centralized management and operations. The series can also be managed with HPE Aruba Networking IMC for a single view of your entire network.
What is new supporting point:
Gigabit Ethernet access switch with static layer 3 routing, RIP, high density 10 GbE uplinks, and POE+ models for voice, video, and wireless.
It supports IRF technology that enables plug-and-play device aggregation and link aggregation across multiple devices, enhancing network redundancy and resource utilization.
It includes embedded network management capabilities with Smart Management Center (SmartMC).
It includes energy-saving green design features such as automatic switching of idle ports to energy-saving mode and powering down unused ports.
