Intel Core i3-6100T 3.2 GHz Skylake, LGA 1151 - processor, boxed
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.Technical details | |
Maximum graphics card memory | 1740 MB |
Video compression formats | |
Number of processors supported | 1 |
PCI Express slots quantity | 16 |
Product type | Processor |
Processor cache | 3072 KB |
Status | Discontinued |
Maximum resolution & refresh rate (DisplayPort) | 4096x2304@60Hz |
Maximum resolution & refresh rate (HDMI) | 4096x2304@24Hz |
Maximum resolution & refresh rate (VGA) | N/A |
Maximum resolution & refresh rate (Integrated Flat Panel) | 4096x2304@60Hz |
OpenGL support | Y |
Launch date | Q3'15 |
Product name | Intel Core i3-6100T (3M Cache, 3.20 GHz) |
Born on date | Q3'15 |
Maximum graphics adapter memory | 64 GB |
Graphics max dynamic frequency | 950 MHz |
Bus type units | GT/s |
Bus bandwidth | 8 |
Maximum memory | 64 GB |
Processor brand name | Intel Core i3 Intel Core i3 Processor |
Last change | 63903513 |
Product family | 6th Generation Intel Core i3 Processors |
Processor | |
Processor model | i3-6100T |
Processor lithography | 14 nm |
Processor family | Intel Core i3 |
Box | |
Processor socket | LGA 1151 |
Stepping | S0 |
Processor cores | 2 |
Processor code | SR2HE |
System bus rate | 8 GT/s |
Processor threads | 4 |
Processor operating modes | 64-bit |
Component for | PC |
Processor cache | 3 MB |
Bus type | DMI3 |
Processor frequency | 3.2 GHz |
Processor codename | Skylake |
Processor cache type | Smart Cache |
Processor series | Intel Core i3-6100 Desktop series |
Memory bandwidth supported by processor (max) | 34.1 GB/s |
Processor ARK ID | 90734 |
Memory | |
ECC | |
Memory channels | Dual-channel |
Maximum internal memory supported by processor | 64 GB |
Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
Memory clock speeds supported by processor | 1333,1600,1866,2133 MHz |
Memory voltage supported by processor | 1.35 V |
Weight & dimensions | |
Processor package size | 37.5 x 37.5 mm |
Energy management | |
Thermal Design Power (TDP) | 35 W |
Operational conditions | |
Tcase | 66 °C |
Other features | |
Maximum internal memory | 64 GB |
L2 cache | 3072 KB |
Video decoding | |
Intel® Virtualization Technology (Intel® VT) | VT-x,VT-d |
Cache memory | 3 MB |
Graphics output | eDP/DP/HDMI/DVI |
Graphics | |
On-board graphics card model | Intel® HD Graphics 530 |
On-board graphics card | |
On-board graphics adapter base frequency | 350 MHz |
On-board graphics adapter dynamic frequency (max) | 950 MHz |
On-board graphics adapter outputs supported | DisplayPort,HDMI,Embedded DisplayPort (eDP),VGA (D-Sub) |
On-board graphics adapter maximum resolution (DisplayPort) | 4096 x 2304 pixels |
On-board graphics adapter ID | 1912 |
On-board graphics adapter 4K support | |
Maximum on-board graphics adapter memory | 1.74 GB |
Number of displays supported (on-board graphics) | 3 |
On-board graphics adapter maximum resolution (HDMI) | 4096 x 2304 pixels |
On-board graphics adapter DirectX version | 12.0 |
On-board graphics adapter OpenGL version | 4.4 |
Processor special features | |
Intel® Identity Protection Technology (Intel® IPT) | |
Intel® Hyper Threading Technology (Intel® HT Technology) | |
Intel® Turbo Boost Technology | |
Intel® Quick Sync Video Technology | |
Intel® InTru™ 3D Technology | |
Intel® Wireless Display (Intel® WiDi) | |
Intel® Clear Video HD Technology (Intel® CVT HD) | |
Intel® Insider™ | |
Intel® Smart Cache | |
Intel® AES New Instructions (Intel® AES-NI) | |
Enhanced Intel SpeedStep Technology | |
Intel Trusted Execution Technology | |
Intel Enhanced Halt State | |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | |
Intel VT-x with Extended Page Tables (EPT) | |
Intel® Small Business Advantage (Intel® SBA) | |
Intel TSX-NI | |
Intel® Secure Key | |
Intel 64 | |
Intel Stable Image Platform Program (SIPP) | |
Intel® OS Guard | |
Intel Virtualization Technology for Directed I/O (VT-d) | |
Intel Clear Video Technology | |
Intel Identity Protection Technology version | 1.00 |
Intel Secure Key Technology version | 1.00 |
Intel Small Business Advantage (SBA) version | 1.00 |
Intel Virtualization Technology (VT-x) | |
Intel Stable Image Platform Program (SIPP) version | 0.00 |
Intel TSX-NI version | 0.00 |
Conflict-Free processor | |
Intel® Optane™ Memory Ready | |
Intel® Memory Protection Extensions (Intel® MPX) | |
Features | |
Bandwidth | 8 MB/s |
Supported instruction sets | SSE4.1,AVX 2.0,SSE4.2 |
PCI Express slots version | 3.0 |
Execute Disable Bit | |
Idle States | |
Thermal Monitoring Technologies | |
Scalability | 1S |
CPU configuration (max) | 1 |
Embedded options available | |
Graphics & IMC lithography | 14 nm |
PCI Express configurations | 2x8,1x8+2x4,1x16 |
Thermal solution specification | PCG 2015A |
Maximum number of PCI Express lanes | 16 |
Market segment | DT |
EAN | 5032037079112 |
Warranty | 3 years |
Your days just got a little bit easier. With fast wake and faster CPU, your processor will last longer and work smarter. Watch movies with crisp pictures thanks to Iris™ graphics technology. Seamlessly change from your PC to your tablet for maximum versatility – all using the 6th Generation Intel® Core™ processors.
Ready. Wake. Create.
From zero to power in a flash, the 6th generation Intel® Core™ processor wakes quicker than ever and lets you switch in and out of apps more seamlessly than ever.
Stunning Visual Experiences
With 6th generation Intel® Core™ Ultra HD graphics, your screen comes to life. Watch in a whole new way with 4k screens. Wireless displays let you create and game anywhere.
Security You Can Trust
Worry-free and hassle-free security is yours. With facial recognition and True Key™ technology, getting you logged in and protected has never been easier or more secure.
