Cisco Small Business SG500X-24 - Kytkin - L3 - Hallinnoitu - 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ - räkkiin asennettava
Manufacturer: CISCO
ID: SG500X-24-K9-G5
Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| Fiber optic connector | SFP+ |
| Combo SFP ports quantity | 2 |
| Installed SFP+ modules quantity | 2 |
| Installed SFP modules quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP+ module slots quantity | 2 |
| Weight & dimensions | |
| Weight | 3.45 kg |
| Height | 44 mm |
| Width | 440 mm |
| Depth | 350 mm |
| Energy management | |
| Power consumption (typical) | 36.5 W |
| AC input frequency | 47/63 Hz |
| AC input voltage | 110 - 220 V |
| Power supply included |  |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 114.7 BTU/h |
| Protocols | |
| Management protocols | SNMP v1/v2c/v3, MIB, HTTP/HTTPS, RMON, IPv4, IPv6 |
| Supported network protocols | TCP/IP |
| Networking | |
| Networking standards | IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Flow control support | |
| Port mirroring | |
| Link aggregation | |
| Broadcast storm control | |
| Rate limiting | |
| Number of VLANs | 4096 |
| Head-of-line (HOL) blocking | |
| VLAN support | |
| 10G support | |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
| Data transmission | |
| MAC address table | 16384 entries |
| Switching capacity | 128 Gbit/s |
| Jumbo frames support | |
| Number of queues | 8 |
| Packet buffer memory | 12 MB |
| Throughput | 95.24 Mpps |
| Number of static routes | 2048 |
| Number of IP interfaces | 256 |
| Jumbo frames | 9216 |
| Packaging data | |
| Cables included | AC, Serial |
| Quick start guide | |
| Mounting brackets included | |
| Resource CD | |
| Security | |
| Security algorithms | 802.1x RADIUS,SSH,SSL/TLS |
| Access Control List (ACL) | |
| SSH/SSL support | |
| Loop protection | |
| BPDU filtering/protection | |
| Management features | |
| MIB support | Y |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | |
| Web-based management | |
| Switch type | Managed |
| ARP inspection | |
| Design | |
| Certification | UL (UL 60950), CSA (CSA 22.2), CE mark, FCC 15 (CFR 47) |
| LED indicators | Link, PoE |
| Product colour | Black |
| Stackable | |
| Reset button | |
| Number of fans | 1 fan(s) |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) |  |
| Performance | |
| Processor frequency | 800 MHz |
| Internal memory | 256 MB |
| Mean time between failures (MTBF) | 246188.2 h |
| Flash memory | 32 MB |
| Minimum system requirements | Mozilla Firefox 3.6+ IE 7+ |
| Noise level | 40.2 dB |
| Compatible operating systems | Windows, Linux, Mac OS X |
| Firmware upgradeable | |
| Built-in processor | |
| Multicast features | |
| Multicast support | |
| EAN | 882658424809 |
| Warranty | 2 years |
| Source: Icecat.biz | |
The Cisco SG500X-24 is a 24-port stackable managed Gigabit Ethernet switch, with 4 Enhanced Small Form-Factor Pluggable (SFP+) slots and optional 10 Gigabit Ethernet connectivity, that provides a solid foundation for your current business applications, as well as those you are planning for the future. It offers true stacking, advanced security, quality of service, energy-saving technology (EEE), IPv6, and network features that deliver the reliability and performance needed by demanding environments. The switch is easy to configure and manage with a choice of management tools and is offered with a limited lifetime warranty, including next-business-day advance replacement and one year of technical support. The Cisco SG500X-24 provides the ideal technology foundation at a price you can afford, and in a solution designed to grow with your business.
- Layer 3 - Managed
- 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ ports
- Rack-mountable
- Stackable
- Layer 3 - Managed
- 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ ports
- Rack-mountable
- Stackable
